🔋 STF Lithium Iron Phosphate (LiFeP04) Cells
Your choice of compact Cylindrical (6Ah) or versatile Prismatic (100Ah) power solutions.
Introducing the Siri Technofabs (STF) LiFeP04 Cells (Lithium Iron Phosphate) rechargeable cells. We offer two core formats to fit your exact power needs: the compact, high-discharge Cylindrical 32700 (6Ah) cell and the versatile, high-capacity Prismatic (100Ah) cell. Both are engineered for superior safety, stability, and an extended life cycle, making them the ultimate fit-and-forget solution for demanding applications, backed by a strong warranty.
Why STF LiFeP04? Superior Performance Across All Formats
LiFeP04 technology is the preferred choice for leading Electric Vehicle (EV) Battery Pack users, large-scale Energy Storage Systems (ESS), and critical systems requiring increased lifespan and higher performance.
Superior Safety
The phosphate-based cathode is chemically much more stable and non-combustible. It will not burn even under high temperatures or if mishandled, ensuring maximum safety for EVs and mobile robotics.
Extreme Longevity
Both cell types offer a significantly longer lifetime than Lead Acid and standard Li-ion cells, providing more than 3000 cycles under proper handling (up to 70% DOD).
High Performance
Provides stable, consistent power output with very little voltage drop during discharge, a major advantage over Lead Acid batteries.
Eco-Friendly
LiFeP04 is a non-toxic, non-contaminating material that contains no rare-earth minerals, making it an environmentally conscious choice.
Warranty & Assurance 🛡️
Warranty & Assurance 🛡️
STF is confident in the longevity and quality of our LiFeP04 cells, offering application-specific warranties for your peace of mind:
Ideal Applications
STF cells are built to power the future, offering unparalleled performance and warranty-backed reliability for:
Cell Specifications at a Glance
A quick comparison of the two primary cell formats available:
| Feature | 32700 Cylindrical Cell | 100Ah Prismatic Cell |
|---|---|---|
| Capacity | 6000 mAh (6 Ah) | 100 Ah |
| Form Factor | 32650 / 32700 (32mm×70mm) | Prismatic (Rectangular, e.g., ~220mm×130mm×40mm) |
| Nominal Voltage | 3.2V | 3.2V |
| Max. Continuous Discharge | 1C (6A) | 1C (100A) |
| Max. Peak Discharge | 3C (18A) | 3C (300A) |
| Life Cycle | >3000 cycles | >3000 cycles |
| Application Focus | High-power output, compact battery packs. | High-capacity energy storage, modular packs, EV/ESS. |
Detailed Cell Specifications
In-depth parameters for both cylindrical and prismatic formats:
3.2V 32700 / 32650 (6000mAh) LiFeP04 Cell
| Parameter | Specification |
|---|---|
| Nominal Voltage | 3.2V |
| Nominal Capacity (0.2C) | 6000mAh |
| Charging Cut-off Voltage | 3.7V |
| Discharging Cut-off Voltage | 2.5V |
| Max. Charging Current (Continue) | 1C (6A) |
| Max. Discharging Current (Instantaneous) | 3C (18A) |
| Cell’s Diameter | 32mm |
| Cell’s Height | 70mm |
| Cell’s Weight | 145g |
| Operating Temp (Discharge) | 0°C~45°C |
3.2V 100Ah Prismatic LiFeP04 Cell
| Parameter | Specification |
|---|---|
| Nominal Voltage | 3.2V |
| Nominal Capacity | 100Ah |
| Charging Cut-off Voltage | 3.65V |
| Discharging Cut-off Voltage | 2.5V |
| Max. Charging Current (Continue) | 1C (100A) |
| Max. Discharging Current (Instantaneous) | 3C (300A) |
| Approximate Dimensions (L × W × T) | ~220mm×130mm×40mm |
| Approximate Cell Weight | ~2.1kg−2.5kg |
| Operating Temp (Discharge) | -20°C~60°C |
Ready to electrify your fleet?
Contact our specialists for a tailored analysis of the best LiFeP04 cells.
